Warehouse Robot Battery
Product Details:
Product Description
Established in the year 2006, we are engaged in the business of manufacturing and supplying Warehouse Robot Battery that provides the power source to modern robots. They need a battery that is safe, lightweight and gives a longer working life. This battery is generally of two types; silver cadmium and lead acid batteries. It can be rechargeable or non-rechargeable. The Warehouse Robot Battery has a wide operating temperature range, high efficiency& reliability. The power to weight ratio is relatively large compared to other batteries.
Features:
- Operating temperature is 0 to 45°C
- Nominal voltage is 25.9 V
- Cell capacity is 5000 mAh
Technical Specifications:
| Specification | Auto Warehouse Battery |
|---|---|
| Cell Voltage | 3.7 V |
| Cell Capacity | 5000 mAh |
| Typical Pack Capacity | 60,000 mAh ± 5% |
| Nominal Voltage | 25.9 V |
| Charge Voltage | 29.4 V |
| End of Discharge (Voltage) | 21 V |
| Charge Current | 12 A |
| Discharge Current | 15 A |
| Discharge Current (Max) | 58 A |
| Operating Temperature | 0 ~ 45 °C |
| Storage Temperature | -20 ~ 40 °C |
| Storage Humidity | RH 45 ~ 85% |
| Power Consumption | 740 µA |
| Initial Internal Resistance | 40 m |
| Cycle Life | 42,000 mAh (after 1000 cycles) |
| Dimensions | 347 mm x 310.2 mm x 119.5 mm |
| Weight | 22 kg |
